BST H 18000 Lbs
zł4,969.00
VAT included
EAN13: 5904024534280
BST H 18000lbs | Technical specifications | ||
Pulling rate | 8165 kg | ||
Motor displacement | 80ml/r | ||
Oil flow | 5~60L/min | ||
Pressure | 13Mpa | ||
Gear | 2 -stage planetary | ||
Gear ratio | 34:1 | ||
Rope | 26,5m x Ø 12 mm | ||
Fairlead | 4-ways rollers fairlead | ||
Net weight | 69 kg | ||
Mounting bolt pattern | 254mm×114.3mm | ||
Dimensions | (L x W x H) 541mm ×390mm ×320mm |
Line speed and motor current (first layer) | ||||||
Line pull | Lbs | 0 | 10000 | 12000 | 15000 | 18000 |
Kgs | 0 | 4536 | 5443 | 6843 | 8165 | |
Line speed | m/min | 0,5 | 2,0 | 3,0 | 5,5 | 6,0 |
Pressure | Mpa | 2 | 4,3 | 8,7 | 10 | 13 |
Oil flow | l/min | 5 | 10 | 20 | 30 | 60 |
Line pull and cable capacity | ||||||
Layer of cable | 1 | 2 | 3 | 4 | ||
Rated line pull per layer | Lbs | 18000 | 12120 | 10168 | 8757 | |
Kgs | 8165 | 5498 | 4612 | 3972 | ||
Cable capacity per layer | M | 5,5 | 12,4 | 20,1 | 26,5 |
Data sheet
- Rodzaj liny
- Lina stalowa
- Siła uciągu
- 18000lbs (8164kg)
