BST H 12000 Lbs
zł3,869.00
VAT included
EAN: 5904024534259
A hydraulic winch is an advanced tool designed for work in extreme conditions that require high pulling strength and precise control over the moved loads. Thanks to the use of hydraulic drive, this winch offers impressive pulling power, making it an ideal solution for use in construction, heavy industry, and workshops. The winch ensures efficiency, reliability, and safety in tough working conditions, providing fast and effective movement of loads.
Hydraulic drive – provides high power that is smoothly and precisely controlled, ensuring effectiveness in every application.
High-quality materials – a corrosion-resistant steel construction that ensures the longevity of the winch.
| BST H 12000lbs | Technical specifications |
| Pull capacity (single line) | 12000 lbs (5443kg) |
| Motor displacement | 65 ml/r |
| Oli flow | 5～45 L/min |
| Pressure | 14 Mpa |
| Gear | 2-stage planetary |
| Gear ratio | 25,5:1 |
| Rope | 25,5 m x 10,2 mm |
| Weight | 56 kg |
| Dimentions | 519 mm x 235 mm x 246 mm |
| Mounting bolt pattern | 254mm×114.3mm |
| Fairlead | 4-ways rollers fairlead |
| Line speed and motor current (first layer) | ||||||
| Lbs | 0 | 3000 | 6000 | 9000 | 12000 | |
| Line load | Kg | 0 | 1361 | 3629 | 6804 | 9072 |
| Line speed | m/min | 0,7 | 1,4 | 2,7 | 4,6 | 5,1 |
| Oli pressure | PSI | 290,1 | 652,7 | 986,2 | 1305,3 | 1812,9 |
| Oil flow | l/min | 5 | 10 | 20 | 35 | 40 |
| Line pull and cable capacity | |||||
| Layer of cable | 1 | 2 | 3 | 4 | |
| Lbs | 12000 | 9000 | 6000 | 3000 | |
| Rated line pull per layer | Kg | 5543 | 4082 | 2722 | 1362 |
| Cable capacity per layer | m | 5 | 11,3 | 18,6 | 25,5 |
Data sheet
- Type of rope
- Steel rope
- Pulling force
- 12000lbs (5443kg)
- manufacturer
- Kwella sp. z o.o.
- Importer
- Kwella sp. z o.o.
