- Out-of-Stock
EAN13: 5903738831128
BST 8500lbs | Technical specification | |
Pull capacity(single line) | 8500lbs / 3856 kgs | |
Motor 12V | 5.5 hp | |
Controls | Wired / wireless remote control | |
Gear | 3-stage planetary | |
Gear ratio | 218:1 | |
Brake | Automatic | |
Rope | 24m | |
Fairlead | 4-ways rollers fairlead | |
Net weight | 32 kg | |
Mounting bolt pattern | 166mm x 114,3mm | |
Dimensions | (L x W x H) 430 X 160 X 218mm |
Line speed and motor current (first layer) | ||||||
Line pull | Lbs | 0 | 2000 | 4000 | 6000 | 8500 |
Kg | 0 | 907 | 1814 | 2722 | 3855 | |
Line speed | M/min | 7,8 | 4,88 | 3,63 | 2,98 | 2,44 |
Motor current | Amps | 80 | 130 | 180 | 230 | 290 |
Line pull and cable capacity | ||||||
Layer of cable | 1 | 2 | 3 | 4 | ||
Rated line pull per layer | Lbs | 8500 | 6640 | 5600 | 4800 | |
Kgs | 3855 | 3012 | 2540 | 2177 | ||
Cable capacity per layer | M | 6 | 13,2 | 22 | 28 |
Data sheet
